A selection guide for Schneider Electric medium‑voltage distribution equipment, covering FP, HVX, CVX, VXA‑VXB, VAH, AS12 and Fusarc CF series.
This guide provides technical parameters, dimensions, and ordering information for Schneider Electric’s medium‑voltage product families. It includes detailed tables for circuit breakers, vacuum contactors, switchgear, and related accessories.
The document is organized into four main sections: product selection for circuit breakers and contactors, relay protection devices, secondary distribution switchgear, and primary distribution switchgear, followed by an overview of E‑House solutions for custom installations. This manual is written in Chinese.
| Rated voltage (FP series) | 7.2–40.5 kV |
|---|---|
| Short‑circuit breaking capacity (FP series) | 25 kA – 50 kA |
The HVX 12 kV model is rated for short‑circuit breaking currents of 25 kA, 31.5 kA, 40 kA and 50 kA.
They are rated for up to 30,000 mechanical operations over their service life.
