The Schneider Electric Acti 9 Product Catalog presents the fifth‑generation modular low‑voltage distribution system, with product overviews, specifications…
This catalog introduces Schneider Electric's Acti 9, the fifth‑generation modular distribution system designed for safety, flexibility and simplicity. It includes an overview of the system concept, product numbering rules and an alphabetical index to help users locate specific items.
The document lists protection, control and installation products such as miniature circuit breakers, residual‑current devices, surge protectors and mounting accessories, providing technical parameters, IP ratings and environmental limits for each component. This manual is written in Chinese.
| Insulation voltage (Ui) | 500 V AC |
|---|---|
| Impact voltage (Uimp) | 6 kV |
| Single‑pole breaking capacity (Icn1) | 6000 A |
| Protection class (body) | IP20 |
| Protection class (installed) | IP40 |
| Operating temperature range | -35 °C to +70 °C |
| Storage temperature range | -40 °C to +85 °C |
The insulation voltage is 500 V AC.
It is rated for a 6 kV impact voltage.
The breaker body is IP20, and when installed in a distribution box it is IP40.
They operate from –35 °C to +70 °C and can be stored from –40 °C to +85 °C.
