Safety Warning Symbol
This manual begins with important safety instructions, warning users about dangerous voltages, proper grounding, and the need to keep the unit away from moisture and liquids. It also outlines basic handling rules, such as not opening the enclosure and referring all servicing to qualified personnel.
The remainder of the guide describes the equalizer’s controls – level LEDs, gain, low‑cut and high‑cut filters, bypass, range selection, and power switch – and explains how to set up and adjust the dual‑channel 31‑band graphic equalizer for live or studio use.
| Filter Type | 1/3 octave ISO center frequencies |
|---|---|
| Frequency Range | 20 Hz – 20 kHz |
| Gain Range | Selectable ±6 dB or ±12 dB |
| Low‑Cut Filter Roll‑off | 18 dB per octave |
| High‑Cut Filter Roll‑off | 18 dB per octave |
| Inputs / Outputs | XLR balanced inputs and outputs |
| Ground Lift Switch | Provides ground‑lift capability |
