The OKI ML7033 is a dual‑channel line‑card CODEC IC with integrated A/D and D/A converters for voice applications.
The ML7033 is a 2‑channel Line Card CODEC CMOS IC designed for voice signals (300‑3400 Hz). It integrates analog‑to‑digital and digital‑to‑analog converters on a single 64‑pin QFP package and operates from a single 5 V supply with low power consumption.
The device offers selectable master clocks (2.048 MHz or 4.096 MHz), serial PCM data rates from 256 kHz to 4.096 MHz, and a range of built‑in tone generators, loop‑back functions, and SLIC interface signals, making it suitable for line‑card and subscriber line interface circuit (SLIC) applications.
| Typical Power Consumption (2‑channel) | 115 mW |
|---|---|
| Package Type | 64‑pin plastic QFP (QFP64‑P‑1414‑0.80‑BK) |
| Master Clock Options | 2.048 MHz or 4.096 MHz selectable |
| Serial PCM Data Rate | 256 kHz – 4.096 MHz |
It is a dual‑channel codec, providing two independent A/D and D/A conversion paths.
Typical power consumption is 115 mW in the 2‑channel operating mode.
The IC is supplied in a 64‑pin plastic QFP package (QFP64‑P‑1414‑0.80‑BK).
