This manual provides installation, wiring, hardware setup, and software configuration instructions for the NStar access control system.
The guide begins with safety warnings and preparation steps, covering power disconnect, voltage verification, grounding, and fire‑safety requirements. It then details hardware installation, including controller placement, wiring of power, RS‑232/RS‑485, door sensors, locks, and accessories.
Subsequent sections describe the software installation, login procedures, communication settings, controller configuration, card registration, system testing, reporting, and maintenance. Appendices and communication wiring diagrams complete the documentation. This manual is written in Chinese.
| Power supply voltage | 16.5 VAC, 50 VA |
|---|---|
| RS‑232 cable length | 15 m |
| RS‑485 maximum cable length | 1200 m |
| Maximum controller‑to‑door distance | 20 m |
Disconnect all external power sources, verify that the supply voltage is within the required range, do not power the system before installation, ensure proper grounding, and follow local fire‑safety regulations.
Use 18 AWG shielded twisted‑pair for the main power (16.5 VAC, 50 VA), a 15 m RS‑232 cable, and a 24 AWG shielded twisted‑pair RS‑485 cable up to 1200 m.
The controller should be no more than 20 meters from each controlled door to maintain proper lock voltage.
Honeywell recommends using DC‑powered electric locks with electromagnetic protection, such as the S‑4 protector.
