Mercury S105M/S108M 10/100M Adaptive Ethernet Switch User Manual

User manual for the Mercury S105M/S108M 10/100M adaptive Ethernet switch, covering installation, configuration, and specifications.

Brand: Mercury
Category: Other Electronics
Document type: User Manual
Language: Chinese
Pages: 10
File format: PDF
File size: 675 KB
Published: 28 September, 2011
Updated: 30 September, 2026
MD5 checksum: 3E47F8E56F36E3CB91512EF35695C94B
PDF: Mercury S105M/S108M 10/100M Adaptive Ethernet Switch User Manual PDF

About this manual

This manual provides instructions for unpacking, installing, and configuring the Mercury S105M/S108M Ethernet switch. It includes details on the front and rear panels, LED indicators, and basic operation.

Technical specifications such as port count, supported Ethernet standards, data rates, environmental limits, and dimensions are listed for reference. This manual is written in Chinese.

What's inside

Introduction
Product Overview
Unpacking and Installation
Front and Rear Panel
LED Indicators
Specifications

Specifications

Port count	5/8 ports
Operating temperature	0 °C to 40 °C
Dimensions	140 mm × 84 mm × 28 mm

Frequently asked questions

How many ports does the Mercury S105M/S108M switch have?

The switch provides 5/8 Ethernet ports.

What are the operating temperature limits?

The device operates between 0 °C and 40 °C.
