The Kikusui 2021‑2022 catalogue presents electronic test and measurement instruments and power supplies with specifications, interfaces and options.
This catalogue from Kikusui Electronics Industrial Co., Ltd. introduces the company's electronic test and measurement instruments and power supplies for the 2021‑2022 period. It includes new product introductions, a model index, and detailed technical specifications for each product family.
Key product families such as the PWR‑01 series, PWX series, and PAT‑T series are highlighted, showing features like LAN (LXI), USB, RS232C interfaces, internal resistance variable function, and parallel/series operation capabilities. The catalogue also provides information on optional accessories, safety standards, and application software. This manual is written in Chinese.
| Communication interfaces (PWR‑01 series) | LAN, USB, RS232C (optional GPIB) |
|---|---|
| Dimensions and weight (400W PWR‑01 model) | 71W×124mm×350mm, approx. 3 kg |
| Maximum power ratings (PWR‑01 series) | 400 W, 800 W, 1200 W, 2000 W |
| Internal resistance variable range | 0 < Rint ≤ Rint(max) |
The PWR‑01 series comes standard with LAN (LXI), USB and RS232C interfaces, and GPIB can be added as an optional adapter.
Yes, the PWR‑01 series supports parallel (master‑slave) operation, with up to three identical units for certain models.
It allows the user to set an internal resistance value (0 < Rint ≤ Rint(max)) to simulate batteries, photovoltaic cells, fuel cells, etc.
The 400 W model measures 71 mm × 124 mm × 350 mm and weighs about 3 kg.
