Kikusui models by category
Featured Kikusui manuals
Kikusui TOS93 Series User Guide
The Kikusui TOS93 Series is a safety‑test composite machine that performs multiple electrical safety tests such as high‑voltage, insulation resistance, ground continuity, and leakage current. The guide provides safety information, installation steps, basic operation, and detailed test procedures for models TOS9300, TOS9301, TOS9302, TOS9303 and TOS9303LC.
The manual also describes system settings, external control options, storage functions, maintenance tasks, and full technical specifications, including supported standards (IEC, EN, BS, VDE, UL, CSA, GB, JIS) and interface options (LAN, USB, RS‑232C).
Covers: For Ensuring Test Safety · Installation and Preparation · Basic Operation · Voltage Test / Insulation Resistance Test · Ground Continuity Test · Contact Current Test
Kikusui TOS93 Series Electrical Safety Analyzer User Manual
This manual covers the Kikusui TOS93 series electrical safety analyzer, describing its safety interlock, required accessories, and the various test functions such as withstanding voltage, insulation resistance, earth continuity, partial discharge, touch current, protective conductor current, and patient leakage current. It also explains how to configure the device, use the front‑panel controls, and perform remote control via SCPI commands.
Additional sections detail environmental requirements, power‑cord specifications, interface options (LAN, USB, RS232C), and warranty information. The document includes a table of contents, component names, safety warnings, and an appendix with specifications and troubleshooting guidance.
Covers: Safety Precautions for Testing · Installation · Basic Operation · Test Types (Withstanding Voltage, Insulation Resistance, Earth Continuity, Partial Discharge, Leakage Current) · Meter Mode and Auto Test · External Control and Memory Function
KIKUSUI TOS9201/TOS9200/TOS9221/TOS9220/TOS8870A/TOS5101/TOS5051/TOS5050/TOS5030/TOS5052/TOS7200/TOS6200 Manual
The TOS9200 Series includes the TOS9200, TOS9201, TOS9220, TOS9221, TOS6200, TOS7200 and related models. These instruments perform AC/DC withstanding voltage, insulation resistance, and earth continuity tests to meet international safety standards such as IEC, EN, VDE, BS, UL, CSA and JIS.
Key features include rise‑time and fall‑time control, offset cancel, voltage hold, memory and program functions, as well as remote operation via GPIB or RS‑232C. Optional accessories such as remote control boxes and high‑voltage test leads are listed with dimensions and voltage ratings.
Covers: Quick Reference · Basic Performance · Rise‑time Control Function · Memory Function · Program Function · Remote Control Box
Kikusui TOS6210 Earth Continuity Tester User Manual
The TOS6210 is a high‑current earth continuity tester that complies with multiple safety standards such as IEC, UL, and JIS. It uses a constant‑current PWM driving method to deliver a smooth current rise and maintains a safe output voltage below the limits required by many standards.
The device includes a panel memory that can store up to 100 test conditions, supports GPIB and RS‑232C remote control, and offers functions like offset‑cancel, contact‑check, and key‑lock to meet various field requirements. This manual is written in Japanese.
Covers: Safety Standards · Test Current and Waveform · Panel Memory Function · Contact Check Function · Offset Cancel Feature · Interface Options
Latest Kikusui manuals
Kikusui TOS93 Series User Guide
User Manual 293 pages · 11 MB · ENUser guide for Kikusui TOS93 safety‑test composite machine covering operation, settings, and safety procedures.
Kikusui TOS93 Series Electrical Safety Analyzer User Manual
User Manual 340 pages · 18 MB · ENThe Kikusui TOS93 series electrical safety analyzer user manual provides safety precautions, installation, operation, and maintenance instructions.
KIKUSUI TOS9201/TOS9200/TOS9221/TOS9220/TOS8870A/TOS5101/TOS5051/TOS5050/TOS5030/TOS5052/TOS7200/TOS6200 Manual
User Manual 32 pages · 1.8 MB · ENThe Kikusui TOS9200 Series manual describes operation, specifications, and programming of its withstanding voltage, insulation resistance, and earth…
Kikusui TOS6210 Earth Continuity Tester User Manual
User Manual 4 pages · 462 KB · JAThe Kikusui TOS6210 Earth Continuity Tester manual provides operation instructions, safety standards, specifications, and interface details.
KIKUSUI TOS5300 series Manual
Kikusui DME1600 Digital Multimeter User Manual
User Manual 2 pages · 416 KB · JAThe Kikusui DME1600 digital multimeter user manual provides operating instructions, specifications, and interface details for the DME1600 series.
Kikusui KHA3000 Harmonic/Flicker Analyzer Datasheet
Datasheet 16 pages · 1.4 MB · ENThe Kikusui KHA3000 Harmonic/Flicker Analyzer datasheet outlines its compliance testing features, specifications, and interface options.
KIKUSUI PAK-A/AM series Manual
KIKUSUI PAN-A series Manual
KIKUSUI PAS Manual
Kikusui PAN-A Series DC Power Supply Manual
User Manual 8 pages · 1.2 MB · ZHThe Kikusui PAN‑A series DC power supply manual provides specifications, safety features, remote‑control options and installation guidance.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Kikusui manuals
What power plug options are supplied with the TOS93 series?
The unit can be supplied with NEMA5‑15, CEE777, or GB1002 plugs, rated 125 Vac/10 A or 250 Vac/10 A.
Which test functions are available on the TOS9303LC model?
TOS9303LC supports ACW, DCW, IR, EC, and LC tests, covering high‑voltage, DC voltage, insulation resistance, ground continuity, and leakage current.
What does the safety interlock do when the TOS93 series is first powered on?
The safety interlock prevents any tests from being performed until the SIGNAL I/O plug is connected to release it.
From: Kikusui TOS93 Series Electrical Safety Analyzer User Manual
Which model supports the partial discharge test?
Only the TOS9301PD model includes the partial discharge measurement function.
From: Kikusui TOS93 Series Electrical Safety Analyzer User Manual
Which safety standards does the TOS9200 series comply with?
It complies with IEC, EN, VDE, BS, UL, CSA, JIS and the Electrical Application and Material Safety Law of Japan.
How many test steps can be stored in the TOS9200 series?
The instrument can store up to 500 steps and 100 programs.
