Honeywell Experion PKS DCS System Manual

About this manual

The Experion PKS Distributed Control System (DCS) is a high‑performance control and monitoring solution used in the 2 × 7.5 MW power station project. The manual describes the system architecture, including redundant servers, C200 controllers, and process I/O modules, and explains how to configure and operate the system.

Key sections cover hardware configuration (engineer and operator stations, servers, C200 controller, I/O modules), network topology (information, monitoring, and I/O networks), software configuration (Quick Builder, Control Builder, station setup), monitoring functions, installation procedures, backup and recovery, and firmware updates. This manual is written in Chinese.

What's inside

• Hardware Configuration
• Software Configuration
• System Network Connection
• Device Address Explanation
• C200 Process Controller
• Module Features and Technical Specifications
• System Installation
• System Backup and Recovery
• System Configuration

Specifications

Frequently asked questions

How many engineer stations are included in the system?

The system includes two engineer stations.

What is the transmission speed of the monitoring network?

The monitoring network operates at 5 MB/s.

Which operating system is required for the servers?

Windows 2000 Server English edition is required.

How many C200 process controllers are used?

One C200 process controller is used in the system.
