The PF3000 is a 12‑channel configurable PMIC with multiple voltage regulators, high efficiency and programmable features for consumer and industrial…
The PF3000 Power Management IC provides a configurable architecture with up to 12 output channels, programmable voltages, and on‑chip sequencing. It supports buck converters, LDOs, boost converters and a button‑cell charger, delivering a single‑chip solution for i.MX processors and other embedded systems.
Designed for both consumer‑grade (-40 °C to +85 °C) and industrial‑grade (-40 °C to +105 °C) environments, the device offers high efficiency (>90 %), a compact 7 × 7 mm QFN package, and I²C register control for dynamic voltage scaling and fault protection. This manual is written in Chinese.
| Number of Output Channels | 12 |
|---|---|
| Total Output Current Capability | 7.2 A |
| Input Voltage Range | 2.8 V ~ 5.5 V |
| Consumer Temperature Range | -40 °C ~ +85 °C |
| Industrial Temperature Range | -40 °C ~ +105 °C |
| Package Type | 7 × 7 mm QFN |
| SW1A Output Voltage | 0.70 V ~ 3.3 V, 1.0 A |
The PF3000 operates with an input voltage from 2.8 V to 5.5 V.
It provides 12 configurable output channels.
The device is packaged in a 7 × 7 mm QFN package.
Consumer versions operate from –40 °C to +85 °C, while industrial versions cover –40 °C to +105 °C.
