User guide for the Fluke 1523 and 1524 temperature readers covering safety, setup, operation, and specifications.
The Fluke 1523 and 1524 temperature readers are handheld, battery‑powered instruments that measure temperature using PRT, thermistor, and thermocouple sensors. The guide provides safety information, required accessories, and step‑by‑step instructions for quick installation and operation.
Key sections include safety warnings, standard equipment checklist, quick‑install procedures, detailed specifications, and wiring diagrams for both models. The manual also outlines warranty terms and contact information for authorized service centers.
| Operating temperature range | -10 °C to 60 °C |
|---|---|
| Storage temperature range | -20 °C to 70 °C |
| Power requirement | 3 AA alkaline batteries (12 V DC) or external 12 V DC supply |
| Dimensions (W×H×D) | 96 mm × 200 mm × 47 mm (3.75 in × 7.9 in × 1.86 in) |
| Weight | 0.65 kg (1.4 lb) |
It is powered by three AA alkaline batteries providing 12 V DC, or it can be run from an external 12 V DC supply.
The instrument can operate from –10 °C to 60 °C.
It complies with EN 61010‑1 (2001) and CAN/CSA C22.2 No. 61010.1‑04.
