The FAST FSG124 user manual provides product overview, hardware installation, performance features, and LED indicators for the 24‑port gigabit Ethernet switch.
This manual describes the FAST FSG124 24‑port gigabit Ethernet switch, covering its purpose, basic functions, and key specifications. It includes sections on product introduction, performance characteristics, hardware installation, and front‑panel indicators.
The document guides users through safe installation on a stable surface or rack, wiring, initial configuration, and explains the meaning of the LED status lights. An appendix provides detailed technical data and regulatory information. This manual is written in Chinese.
| Number of ports | 24 RJ‑45 10/100/1000 Mbps |
|---|---|
| Port mode support | 10 Mbps half/full, 100 Mbps half/full, 1000 Mbps full‑duplex |
| Flow control | IEEE 802.3x full‑duplex and half‑duplex |
| Port security | IEEE 802.1X |
| MAC address table | 8 K entries |
| Dimensions | 440 mm × 180 mm × 44 mm |
| Power input | 100‑240 V, 50/60 Hz |
| Operating temperature | 0 °C ~ 40 °C |
| Storage temperature | -40 °C ~ 70 °C |
| Relative humidity | 59 % ~ 95 % RH |
It provides 24 RJ‑45 ports that support 10/100/1000 Mbps speeds.
The front panel includes LEDs for power, 1000 Mbps link speed, Link/Act status, and mode indication.
The device operates from a 100‑240 V AC source at 50/60 Hz.
Place the switch on a stable surface that can support at least 5 kg, avoid heavy objects on top, and use a grounded three‑hole plug.
