Cisco FE 511 provides WAN‑optimized file services for branch offices with integrated hardware and ActaStor software.
The Cisco FE 511 File Engine is a WAN‑optimized appliance that consolidates branch‑office data to a central data‑center server, delivering low‑latency file access and reducing total cost of ownership. It supports edge and core deployment modes and includes the ActaStor 2.5 software for caching, replication, and policy‑based distribution.
Key hardware specifications include a 2.8 GHz CPU, 512 MB SDRAM, 80 GB SATA disk, dual 10/100/1000BASE‑T interfaces, and a 300 W power supply. The device is rack‑mountable (1 RU), operates from 100‑240 VAC, and meets multiple safety and EMC standards. It can support hundreds of edge users and thousands of core users, with built‑in high‑availability and centralized management features. This manual is written in Chinese.
| CPU | 2.8 GHz |
|---|---|
| Memory | 512 MB SDRAM |
| Disk | 80 GB SATA |
| Network Interfaces | 2 × 10/100/1000BASE‑T |
| Power Supply | 300 W AC |
| Dimensions (H × W × D) | 1.72 in × 17.3 in × 20 in |
| Weight | 28 lb (12.7 kg) |
It provides WAN‑optimized file services for branch offices, consolidating data to a central data‑center server.
The device runs ActaStor v2.5 software for caching and file distribution.
Each core file engine can support thousands of users.
The appliance accepts 100‑127 VAC or 200‑240 VAC and consumes up to 300 W.
