The Agilent N9320A Spectrum Analyzer User Manual provides operating instructions, safety guidelines, and detailed feature descriptions.
This manual covers the N9320A spectrum analyzer, describing its front‑ and rear‑panel layout, safety and environmental requirements, power specifications, and basic operation procedures. It also includes troubleshooting tips, firmware information, and remote‑control capabilities.
Key features highlighted are the 9 kHz‑to‑3 GHz frequency range, high‑sensitivity pre‑amplifier, four independent signal traces, single‑sideband phase‑noise measurement, 0.1 Hz resolution bandwidth, and a USB interface for saving screenshots and data. This manual is written in Chinese.
| Frequency range | 9 kHz – 3 GHz |
|---|---|
| Resolution bandwidth | 0.1 Hz |
| Number of signal traces | 4 independent traces |
| USB interface | Supports screenshot saving (JPG) to USB drive |
| Phase‑noise measurement | Automatic single‑sideband phase‑noise measurement (dBc/Hz) |
| Pre‑amplifier | High‑sensitivity front‑end pre‑amplifier up to 3 GHz |
It covers frequencies from 9 kHz up to 3 GHz.
The instrument can display four independent signal traces simultaneously.
Yes, it includes a USB port that allows saving screen captures as JPG files to a USB drive.
The frequency counter provides a resolution of 0.1 Hz.
