AE623 wireless receiver digital display meter is a wireless receiver meter developed by Hua Xia Anyi Technology Co., Ltd. The main function is to receive the signals of our wireless products for display, control, alarm, and signal conversion. It can receive multiple wireless signals and a single device can receive multiple devices, which can reduce the number of devices, reduce costs, and save space. It can simultaneously receive pressure transmitters, temperature transmitters, and other mixed wireless signal modules.
The AE623 wireless receiver digital meter, developed by Huaxia Anyi, receives signals from the company’s wireless pressure, temperature, flow and density transmitters and converts them to RS232, RS485 or 4‑20 mA outputs for PLC, DCS, RTU or PC integration. It supports multiple wireless channels, clear display, and on‑site monitoring.
This manual provides an overview of the device, its technical specifications, communication protocols, panel operation instructions, programming guide, and example applications. It also details wiring, parameter settings, reset procedures, and how to connect up to 50 wireless devices. This manual is written in Chinese.
| Power supply voltage | AC 220 V ±20 % / DC 24 V ±10 % |
|---|---|
| Output interfaces | RS232 / RS485 |
| Output protocol | MODBUS |
| Transmission frequency | 433 MHz |
| Maximum transmission distance | ≈300 m (line‑of‑sight) |
| Operating temperature range | -40 °C to +85 °C |
| Operating humidity range | 5 % to 95 % (no condensation) |
| Supported baud rates | 19200, 14400, 9600, 4800, 2400, 1200 |
| Maximum number of wireless devices | 50 |
Press the “复位” (Reset) key; the system will reset.
The AE623 can handle up to 50 wireless devices simultaneously.
It supports MODBUS and RTU protocols for data output.
Supported baud rates are 19200, 14400, 9600, 4800, 2400 and 1200.
