This guide provides the necessary information to install and commission the Delta ASDA‑B series servo drive and compatible ECMA servo motors. It includes safety precautions, wiring recommendations, environmental requirements, and basic inspection procedures.
The document also lists model‑specific data such as power ratings, cable specifications, dimensions, and weight, and points to additional resources like the operation manual available on Delta's website. This manual is written in Chinese.
| Power rating (model ASD-B0121-A) | 100W |
|---|---|
| Power cable wire gauge (R, S, T) | 2.1 mm² (AWG14) |
| Storage temperature range | -20 °C to +65 °C |
No. Connecting three‑phase power to the motor U, V, W terminals will damage the servo drive and may cause injury.
The encoder (PG) feedback cable can be up to 20 m (65.62 ft) long.
