This document provides detailed information on the TM238 LDD24DT / LFDC24DT, including electrical safety information, operating instructions, and installation instructions.
This guide provides safety instructions, installation steps and wiring diagrams for the TM238 controller equipped with LDD24DT and LFDC24DT modules. It details connector identification, power‑supply wiring, input and output wiring, and required protective components.
The document also includes warnings about hazardous locations, polarity protection, and recommended fast‑blow fuses. All work must be performed by qualified personnel and only in non‑hazardous environments.
| Number of fast inputs | 8 |
|---|---|
| Number of standard inputs | 6 |
| Number of fast transistor outputs | 4 |
| Number of standard transistor outputs | 6 |
| Recommended output fuse | 0.5 A fast‑blow fuse |
No, the equipment must be installed only in non‑hazardous locations.
