This document is about the product specifications of the C3453CN camera solution, introducing the features and characteristics of the EH1512 series protective enclosure. These include low cost, compact and innovative design, highly reliable die-cast structure, chain link cover, tamper-proof hardware, and cable access seal. The enclosure is designed for indoor and outdoor applications, compliant with IP66 and NEMA Type 4X standards, and easy to maintain and install. It offers factory-installed low-power heater and fan with 24 VAC camera power supply, and has available feed-through conduit mounting models. The EH1512 series is suitable for small to medium-sized analog and IP cameras and can be installed on Pelco's EM1512 or EM1450 mounting brackets.
This manual provides step‑by‑step instructions for installing the Schneider EH1512 camera shield in indoor or outdoor environments. It includes mechanical characteristics, mounting hole locations, and recommended heating elements for temperature control.
The document also lists the product’s key specifications such as dimensions, weight, IP66/NEMA ratings, operating temperature range, and available power options, along with safety certifications and a three‑year warranty. This manual is written in Chinese.
| Weight | 2.50 kg (EH1512) |
|---|---|
| IP rating | IP66 |
| NEMA rating | NEMA 4X |
| Operating temperature | -10 °C to 120 °C |
| Power options for heater | 24 VAC, 120 VAC, or 230 VAC |
The EH1512 shield complies with IP66.
The heating element can be powered by 24 VAC, 120 VAC, or 230 VAC.
