ATV 312 Inverter product catalog, mainly introduces the inverter's selection guide, introduction, features, models, options, communication bus and network, dialogue tools, configuration tools, braking resistors, line reactors, additional EMC input filters, output filters and motor reactors, SoMove upper computer software, dimensions, wiring diagrams, installation instructions, motor starters, etc.
The guide introduces the ATV312 frequency converter, a 0.18 kW‑15 kW, 200‑600 V three‑phase inverter designed for simple industrial machinery such as material handling, packaging, pumps and fans. It highlights the device’s strong performance, compact construction and ease of installation, and explains how optional communication cards allow integration into master control systems.
Key sections describe the inverter’s technical parameters, available accessories (brake resistors, line reactors, EMC filters, HMI terminals), supported communication protocols (Modbus, CANopen, Profibus, Ethernet/IP, etc.), and configuration tools like SoMove software and mobile Bluetooth apps. Environmental compliance, EMC classes and certification details are also provided. This manual is written in Chinese.
| Power range | 0.18 kW – 15 kW |
|---|---|
| Digital inputs | 6 |
| Communication protocols (standard) | Modbus, CANopen |
The ATV312 supports a power range from 0.18 kW up to 15 kW.
The inverter provides six digital (remote) inputs.
