This document contains general information and technical characteristics of ATV32 variable speed drives, and provides information on preparation before installation.
The guide explains the purpose of the ATV32 variable frequency drive, outlines safety symbols and precautions, and presents the mechanical specifications of the unit. It also describes the different model families (A, B, C, D) and their applicable power ranges.
Detailed installation procedures are provided, including mounting, wiring, control‑section installation, and EMC compatibility notes. Users are directed to Schneider Electric’s website for the latest documentation and support resources. This manual is written in Chinese.
| Input voltage (three‑phase) | 400 V AC |
|---|---|
| Power range (three‑phase) | 0.37 kW to 15 kW (0.5 HP to 20 HP) |
| Model families | A, B, C, D |
The latest documents can be downloaded from Schneider Electric’s website at www.schneider-electric.com.
The ATV32 family includes four model families: A, B, C, and D, each with specific variants such as ATV32H0eeM2, ATV32HUeeM2, etc.
