ST10F296E is a 16-bit MCU with MAC unit, 832 Kbyte Flash memory and 68 Kbyte RAM, manufactured by STmicroelectronics.
The ST10F296E is a 16‑bit microcontroller with a MAC unit, up to 64 MHz CPU clock, 832 KB Flash and 68 KB RAM. It provides a rich set of peripherals including ADC, PWM, CAN, timers and multiple serial interfaces.
This manual describes the device architecture, register map, memory organization, power‑down modes, electrical characteristics and package information, and includes guidelines for bootloader usage and peripheral configuration.
| CPU architecture | 16‑bit MCU with MAC unit |
|---|---|
| Maximum CPU clock | 64 MHz |
| Flash memory | 832 KB |
| RAM | 68 KB |
| ADC resolution | 10‑bit, 32 channels |
| CAN interfaces | Two CAN 2.0B interfaces |
| Supply voltage | 5 V ± 10 % (1.8 V core regulator) |
| Package | PBGA 208 (23 × 23 × 1.96 mm) |
The instruction cycle time is 31.25 ns at 64 MHz.
It is supplied in a PBGA 208 package measuring 23 × 23 × 1.96 mm.
The microcontroller includes 832 KB of on‑chip flash memory.
