This document is about the 4KA72X158T21 Ver.03 product in June 2009, including contact information for Taipei, Taichung, and Kaohsiung. The document provides detailed information on the product's model, machine type, system architecture, connection specifications, basic functions, digital input/output points, communication interfaces, high-speed counters, interrupt inputs, pulse outputs, expansion cards, built-in memory and memory cards.
This manual describes the TECO TP03 programmable controller, covering its basic specifications, system configuration, and available modules. It includes details on power options, RS‑422 PC/PDA interface, and supported AD/DA modules.
Installation, wiring methods, high‑speed counter functions, and troubleshooting procedures are presented with tables and diagrams. A complete command list and special function descriptions are also provided for users and service technicians. This manual is written in Japanese.
| Power Supply (AC) | Supported |
|---|---|
| Power Supply (DC) | Supported |
| Interface to PC/PDA | RS‑422 |
| AD Module Type | TP03‑8AD |
The TP03 uses an RS‑422 interface for PC/PDA communication.
The TP03‑8AD AD module is listed in the specifications.
Yes, the TP03 supports both AC and DC power input types.
