V Series LCD Monitor Quick Setup Guide introduces the package contents, use instructions, features, safety precautions and quick setup steps of the monitor.
This guide provides the essential steps to install the Power Audio V Series LCD Monitor. It covers unpacking, connecting the monitor to a computer via D‑Sub or optional DVI‑D, securing the power cord, and powering up both devices. Safety precautions and recommended accessories are also listed.
The document includes detailed technical specifications such as screen size, resolution, brightness, contrast ratio, input connectors, power requirements, and environmental limits. Service contact information for various regions is provided for warranty and support.
| Screen Size | 18.5 inch (Diagonal 47 cm) |
|---|---|
| Resolution | 1366 × 768 (WXGA) |
| Brightness | 250 cd/m² (Typ) |
| Contrast Ratio | 1000:1 (Typ) |
| Viewing Angle | Horizontal 170°, Vertical 160° |
| Input Connectors | 15‑pin D‑Sub and optional DVI‑D |
| Power Input | AC 100‑240 V, 50‑60 Hz |
| Power Consumption (Operating) | < 25 W |
| Dimensions (W×H×D) | 445.4 × 346.5 × 194.7 mm |
| Net Weight | 3.0 kg |
