Panasonic KX-NS1000 business communication server catalog detailing features, specifications, and optional modules.
The KX-NS1000 is a modular IP‑based business communication server that scales with activation keys and supports up to 16 nodes and 1000 terminals. It integrates voice mail, fax server, and wireless solutions for flexible enterprise use.
The catalog provides hardware specs, supported terminal families, optional gateway cards, and activation key options, helping customers design a solution for offices, hotels, call centers, and factories. This manual is written in Chinese.
| CPU | 650 MHz Dual Core |
|---|---|
| Power consumption (full load) | 50 W |
| Dimensions (W×H×D) | 430 mm × 88 mm × 340 mm |
| Weight (full load) | < 5.1 kg |
| Operating temperature | 0 °C to 40 °C |
| Humidity range | 10 % to 90 % (no condensation) |
| Maximum nodes (integrated network) | 16 |
| Maximum terminals | 1000 |
| Ethernet ports | 2 × 1000 Base‑TX |
| Power supply | 100 V‑240 V AC |
The system can connect up to 1000 terminal devices.
Each configuration supports up to 640 SIP phones.
Full‑load power consumption is 50 W.
The integrated network can support up to 16 nodes.
