A service manual for Icom IC-F80DT/DS and IC-F80T/S UHF TRANSCEIVERS is provided
This service manual provides the latest service information for the Icom IC-F80DT/DS and IC-F80T/S UHF transceivers. It includes detailed specifications, inside views of the front and main units, and step-by-step disassembly instructions for the chassis, main unit, and front unit.
| Frequency coverage | 400-470 MHz, 450-520 MHz |
|---|---|
| Number of conventional channels | 256 channels (Max.) |
| Antenna impedance | 150 Q (Nominal) |
| Operating temperature range | 1-22°F to 140°F |
| Power supply requirement | 7.2 V DC negative ground |
| Maximum permissible deviation | +2.5 kHz (Narrow), +5.0 kHz (Wide) |
| Receive system | Double conversion superheterodyne system |
| Dimensions | 2 5/16 (W)x 5 31/32 (H)x 1 1/2 (D) in |
The transceiver must not be connected to a power supply that uses more than 7.2 V.
An RF signal of more than 20 dBm (100 mW) must not be applied to the antenna connector.
The transceiver operates between 1-22°F and 140°F.
