FrSky R-XSR full duplex receiver, small and powerful, supports ACCESS protocol and SBUS/CPPM protocol, supports 16 channels, working voltage range 3.5V-10V, working current 70mA@5V, can be upgraded through Smart Port
The FrSky R-XSR is a 16-channel full duplex telemetry receiver compatible with ACCESS/ACCST firmware. It features an SBUS/CPPM output that can be switched via a long press of the F/S button, indicated by the state of the BLUE LED. The device supports redundancy functions for master and slave receivers.
| Number of Channels | 16CH |
|---|---|
| Operating Voltage Range | 3.5V~10V |
| Operating Current | 7OmA@5V |
| Dimensions | 16*11*5.4mm (L x Wx H) |
Long press the F/S button on the receiver for 4 seconds until the BLUE LED flashes three times.
The BLUE LED stays lit when the receiver is in SBUS mode.
Yes, with the FrSky ACCESS protocol, you can use the Registration & Automatic binding (Smart Match™) feature.
