This manual explains the location and function of all controls on the RF-2200, including power, tuning, volume, band selectors, and indicator lights. Safety precautions cover proper power connection, battery handling, and temperature limits.
It also details antenna options such as the built‑in gyro‑antenna, telescopic antenna, and external antennas for FM, AM, and SW bands, as well as procedures for calibrating short‑wave tuning and attaching the optional shoulder strap.
| Power supply voltage | 120 V AC, 60 Hz |
|---|---|
| Battery type | Four Panasonic D‑size batteries |
| Earphone/External speaker jack impedance | 8 Ω |
| FM antenna impedance | 75 Ω |
| Maximum operating temperature | 50 °C (120 °F) |
Insert the strap hooks into the hook‑holder cavities on both sides of the cabinet and pull up the strap; adjust the length with the buckle.
