The ADCMP341/ADCMP343 are two low power, high accuracy comparators with a 400 mV reference and programmable hysteresis. Supported applications include portable devices, Li-Ion battery monitoring, handheld instruments, LED/relay driving, optoisolator driving, and control systems.
The ADCMP341/ADCMP343 are dual low power, high accuracy comparators featuring a 400 mV reference and programmable hysteresis via a resistor string. They operate within a supply range of 1.7 V to 5.5 V with a typical quiescent current of 6.5 µA, making them ideal for portable applications and low voltage system monitoring. The devices include open-drain outputs that support wired-AND connections and are available in a small 8-lead SOT-23 package.
| Threshold Voltage | 400.4 mV |
|---|---|
| Threshold Voltage Accuracy | ±0.275 % |
| Supply Range | 1.7 V to 5.5 V |
| Quiescent Current | 6.5 µA typical |
| Input Bias Current | ±5 nA maximum |
| Operating Temperature Range | -40°C to +125°C |
| Package Type | 8-Lead SOT-23 |
The threshold voltage is 400 mV with an accuracy of ±0.275%.
Hysteresis is determined using three resistors in a string configuration connected to the ±INA_U and ±INA_L pins.
The devices operate within a supply range of 1.7 V to 5.5 V.
