The BOSS CEB-3 is a chorus unit specifically designed for electric bass guitar. It features selectable frequency bands and dual channel outputs to create deeper chorus effects. The unit includes controls for effect level, low filter, modulation rate, and modulation depth.
| Nominal Input Level | -20 dBm |
|---|---|
| Input Impedance | 1 MΩ |
| Nominal Output Level | +20 dBm |
| Output Impedance | 1 kΩ |
| Recommended Load Impedance | 10 kΩ or greater |
| Residual Noise Level | -86 dBm (IHF-A, Typ.) |
| Power Supply | 9V DC : Dry Battery 9 V type (6F22/9 V), AC Adaptor |
| Current Draw | 18 mA (9 V DC) |
The BOSS CEB-3 is a chorus unit that is specifically designed for electric bass guitar.
Power is turned on whenever a plug is inserted into the INPUT jack, and is turned off when the plug is disconnected.
If the indicator goes dim or no longer lights while an effect is ON, the battery is near exhaustion and should be replaced immediately.
