Panasonic WVQ169-MUL Manual

This document is an instruction manual for the ceiling mount bracket. It includes information on the installation area, ceiling board thickness requirements, and the features and functions of the product.

Brand: Panasonic
Category: other commodities
Document type: Installation Guide
Language: English
Pages: 16
File format: PDF
File size: 356 KB
Published: 08 August, 2012
Updated: 28 September, 2023
MD5 checksum: 0DF7628AFF8E917737CE739A1D117814
PDF: Panasonic WVQ169-MUL Manual PDF

About this manual

The Panasonic WV-Q169 is a ceiling embedded mounting bracket exclusively designed for the color CCTV camera model WV-NW484S. It features an embedded type design intended to minimize the visible portion of the camera, making it suitable for areas with weak pull-out strength such as plasterboard double ceilings.

What's inside

Preface
Precautions
Major Operating Controls and Their Functions
Installations
Specifications
Standard Accessories

Specifications

Ambient temperature	-10 °C to +50 °C
Dimensions	204.4 mm in diameter x 143.4 mm in height
Weight	Approx. 705 g

Frequently asked questions

What camera is this bracket designed for?

This bracket is exclusively designed to mount the color CCTV camera, WV-NW484S.

What are the installation temperature limits?

The operating temperature range is from -10 °C to +50 °C.
