The Panasonic WV-PS11B is a camera drive unit designed for surveillance and security applications in offices, factories, schools, and other buildings. It is specifically engineered to drive designated Panasonic cameras, including the WV-BP70, WV-CF20, and WV-CP100 models. The unit provides stable DC power and vertical drive pulses via a single coaxial cable, which also carries video and audio signals depending on the connected camera model.
| Power Source | 120 V AC 60 Hz |
|---|---|
| Power Consumption | Approx. 16 W |
| Camera Input | 1.0 V[p-p] / 75 Ω |
| Video Output | 1.0 V[p-p] / 75 Ω |
| Audio Output | -10 dB / 600 Ω |
| Camera Power Supply | Regulated current multiplex method (310 mA) |
| Ambient Operating Temperature | -10 °C - +50 °C |
| Dimensions | 138 (W) X 44 (H) X 185(D) mm |
The unit is designed to drive specified cameras such as the WV-BP70, WV-CF20, or WV-CP100.
A single coaxial cable connects the specified camera and the camera input of the camera drive unit.
The protection circuit will operate and prevent the camera from functioning if the power is on during connections.
