This manual describes the quick setup, monitor, parameters, diagnostics, I/O and hardware, user settings, and favorites features of the VACON 100 drive and its HVAC application.
The document serves as an application manual for the Vacon 100 frequency converter. It details the use of the graphical keypad interface to configure the drive through various wizards, including the Startup Wizard, PID Mini-Wizard, and Multi-Pump Wizard.
Key sections cover specific HVAC applications, explaining how to set up motor parameters, start/stop sequences, ramp settings, I/O configurations, and protection limits. The manual also includes a comprehensive fault tracing section with codes and descriptions for diagnosing issues such as slot faults, communication errors, and thermistor failures.
| Minimum Frequency Range | 0.00...50.00 Hz |
|---|---|
| Maximum Frequency Range | 0.00...320.00 Hz |
| PID Setpoint Range | 0.00...100.00% |
| PID Gain Range | 0.00...200.00% |
| Integration Time Range | 0.00...600.00 s |
Pressing the Back/Reset button at the first question will cancel the Startup Wizard.
Fault Code 54 indicates a Slot fault caused by a defective option board or slot.
