PDIUSBP11 is a one chip generic USB transceiver. It is capable of transmitting and receiving serial data at both full speed (12Mbit/s) and low speed (1.5Mbit/s) data rates.
The Philips PDIUSBP11 is a one-chip generic USB transceiver designed to interface 5.0V or 3.3V programmable logic with the physical layer of the Universal Serial Bus. It supports both full speed (12Mbit/s) and low speed (1.5Mbit/s) serial data transmission.
| Data transmission speeds | 12Mbit/s and 1.5Mbit/s |
|---|---|
| Supply voltage range | 3.0V to 3.6V |
| Operating temperature range | 0°C to +70°C |
| Package type | 14-pin plastic SO, SSOP, TSSOP |
The device supports both full speed (12Mbit/s) and low speed (1.5Mbit/s) data transmission.
The recommended operating conditions specify a DC supply voltage between 3.0V and 3.6V.
