Extech 39272 Pocket Fold-up Thermometer Instruction Manual

The Extech 39272 Fold-up Thermometer is a reliable device that will provide years of dependable service. It features a foldable probe, temperature unit selection, and max/min reading function.


Extech 39272 Pocket Fold-up Thermometer Instruction Manual - cover page
Brand
EXTECH
Category
Temperature sensors
Document type
User Manual
Language
English
Pages
1
File format
PDF
File size
30 KB
Published
01 August, 2012
Updated
28 September, 2023
MD5 checksum
138B23375CF22A63BACAB8C9DD3A6C05

About this manual

The Extech 39272 Pocket Fold-up Thermometer is a stem thermometer designed for reliable temperature measurements. It features a stainless steel sensor and an LCD display capable of showing readings in Celsius or Fahrenheit. The device includes functions for holding the current temperature and recording maximum and minimum values.

What's inside

  • OPERATION
  • Display
  • Measurement ranges
  • Resolution
  • Accuracy
  • Sensor specifications
  • Battery power
  • WARRANTY

Specifications

Display3-1/2 digit LCD with oC/oF degree indicator
Measurement ranges-58 to 572oF (-50 to 300oC)
Resolution0.1oC/F
Accuracy±1.8oF (1oC) from –22 to 482oF (-30 to 250oC)
Sensor length4.5” (117mm)
Sensor materialStainless steel
Operating temperature-14 to 122oF (-10 to 40oC)
Battery power(1) AAA Battery

Frequently asked questions

How do I turn the thermometer on and off?

To turn the meter on, extend the probe away from the body of the thermometer. To turn the meter off, fold the probe completely against the meter.

How do I switch between Celsius and Fahrenheit?

Press the F/C key to select the desired units; the display should indicate the change.

What is the battery requirement?

The device requires one AAA battery, which is replaced by opening the battery compartment.
