CYIV-52001-3.3 is a product document about Altera Corporation. The document describes the features and characteristics of Altera's products, including the ARRIA, CYCLONE, HARDCOPY, MAX, MEGACORE, NIOS, QUARTUS, and STRATIX series. The document also mentions Altera's product warranty policy and disclaimer.
The document describes the transceiver architecture found in Cyclone IV GX devices, which include up to eight full-duplex transceivers with serial data rates between 600 Mbps and 3.125 Gbps. It outlines supported protocols such as PCI Express, Ethernet, CPRI, OBSAI, XAUI, and various video interfaces like HD-SDI and DisplayPort.
The supported serial data rates range up to 3.125 Gbps.
The devices include up to eight full-duplex transceivers.
The FIFO is four words deep.
