NEC Model 9060 Liquid Crystal Projector User's Manual

About this manual

The document serves as a user guide for the NEC Model 9060 Liquid Crystal Projector. It outlines critical safety information regarding electrical shock prevention, fire hazards, and proper handling of high-voltage components inside the cabinet.

Key operational instructions cover installation requirements, such as ensuring adequate ventilation space and avoiding tilting the unit more than 45 degrees from level to preserve lamp life. The manual also details power supply specifications (100-120 or 200-240 V AC) and provides specific procedures for cleaning the lens and replacing the lamp, emphasizing the need to allow cooling time before replacement.

What's inside

• Important Information
• Installation
• Power Supply
• Cleaning
• Lamp Replacement
• Fire and Shock Precautions

Frequently asked questions

How much space is required between the projector and a wall for ventilation?

You must allow at least 3 inches (10 cm) of space between the projector and a wall.

How long must you wait after turning off the projector before replacing the lamp?

You must wait a minimum of 90 seconds (2 minutes in the optional extended life lamp) after turning off the projector.

What is the maximum angle the projector front can be tilted from level?

Tilting the front of the projector up or down by more than 45° from level could reduce lamp life.
