The MR27V3202E is a 32 Mbit electrically Programmable Read-Only Memory that can be electrically switched between 2,097,152-word × 16-bit and 4,194,304-word × 8-bit configurations. This device operates on a single +3.3V power supply, and all inputs and outputs are TTL compatible. Because of its asynchronous operation, it requires no external clocks, making this device easy-to-use. The MR27V3202E is suitable as large-capacity fixed memory for microcomputers and data terminals. It is manufactured using a CMOS double silicon gate technology and is offered in 44-pin SOP or 44-pin TSOP(II) packages.
The MR27V3202E is a 32 Mbit electrically Programmable Read-Only Memory (PROM) manufactured by OKI Semiconductor using CMOS double silicon gate technology. It is designed as a large-capacity fixed memory for microcomputers and data terminals, operating on a single +3.3V power supply with TTL-compatible inputs and outputs. The device features asynchronous operation, requiring no external clocks, and is available in 44-pin SOP or 44-pin TSOP packages.
| Memory Capacity | 2,097,152-word x 16-bit or 4,194,304-word x 8-bit |
|---|---|
| Power Supply Voltage | +3.3V |
| Access Time | 90 ns MAX |
| Operating Current | 50 mA MAX |
| Standby Current | 50 pA MAX |
| Operating Temperature | 0 to 70 °C |
| Storage Temperature | -55 to 125 °C |
| Packages | 44-pin plastic SOP or 44-pin plastic TSOP |
It can be electrically switched between 2,097,152-word x 16-bit and 4,194,304-word x 8-bit configurations.
No, because of its asynchronous operation, it requires no external clocks.
The device is offered in 44-pin plastic SOP or 44-pin plastic TSOP packages.
