RN5T562 is a chip that integrates CMOS step-down DC/DC converter and two low dropout regulators (LDO). With some external components such as inductor, capacitors and resistor, it is easy to compose a low ripple, high efficiency step-down DC/DC converter.
The RN5T562 is a CMOS-based integrated circuit that combines a self-oscillating step-down DC/DC converter with two independently controllable LDOs. It features a high switching frequency of up to 2MHz, allowing the use of small external inductors and capacitors. The device includes protection circuits such as Under Voltage Lockout (UVLO) and Thermal Shutdown.
| Input Voltage Range (DC/DC) | 3.1V to 4.5V |
|---|---|
| Maximum Output Current (DC/DC) | 500mA |
| Output Voltage Range (LDOs) | 1.2V to 3.3V |
| Maximum Output Current (LDOs) | 200mA |
| Package Type | QFN 16pins, 3mm X 3mm |
| Self-oscillation Frequency | up to 2MHz |
Both LDO1 and LDO2 outputs can be settable in 0.05V steps within a range of 1.2V to 3.3V.
The device operates within a temperature range of -40°C to +85°C.
