SHS TM solar controller has 2 models, SHS-6 and SHS-10, with maximum output power of 100W and 170W respectively. The controller has short circuit and overcurrent protection, reverse polarity protection, reverse current protection, and high voltage protection.
The document provides user instructions for the Morningstar SHS series of solar charge controllers. It details the specific models available (SHS-6 and SHS-70) and their respective ratings, as well as the Night Light variants (SHS-NL-6 and SHS-NL-10). The guide explains how to connect wires in the correct order and interpret the LED status indicators for solar charging, battery levels, and load states.
| Voltage System | 12V systems only |
|---|---|
| SHS-6 Rating | 100 Watts or 6 Amps |
| SHS-70 Rating | 170 Watts or 10 Amps |
| Regulation Point | 14.3 Volts |
| Low Voltage Disconnect | 11.5 Volts |
| Charging Type | Series PWM |
| Dimensions | 15.1x 6.6x3.6 cm |
The SHS-70 model supports up to 10 Amps for both solar and load.
The Green light indicates that solar is charging the battery (ON) or that the battery level is full (ON).
A blinking Red light means the battery level is low.
