This manual describes the supplied materials, overview, installation, ceiling mount, start-stop, image adjustments, remote control and keypad, menu adjustments, light messages, power management (DPMS) and troubleshooting of BOXLIGHT XP-60m/SP-50m
The BOXLIGHT XP-60m/SP-50m is an LCD projector supplied with essential accessories including a power cord, audio/video cables, remote control, and soft case. The device features adjustable feet for stability, ventilation inlets and outlets for cooling, and an IR sensor for remote operation.
To set up the projector, connect it to data sources via VGA or USB mouse cable, video sources via Audio/Video or S-Video cables, and power using the provided cord. Once connected, turn on the projector followed by the source device. The manual also details procedures for ceiling mounting, image adjustments, menu settings, troubleshooting common issues, and lamp replacement. This manual is written in German.
| Mounting Screw Type | M4 screw |
|---|---|
| Minimum Ceiling Distance | 30/50 cm, 12/20 inch |
Use the included Audio Cable to connect from the projector's Audio in port to the computer.
The minimum distance from the ceiling or rear wall must be 30/50 cm (12/20 inch) to ensure proper ventilation.
