LMP7711 is a precision amplifier with low noise, low offset, CMOS input, and rail-to-rail output characteristics, suitable for various instrumentation applications. It features an input bias current of 100 fA, input referred voltage noise of 5.8 nV/, and an input offset voltage of less than ±150 µV, making it ideal for precision applications.
The LMP7711 is a low noise, low offset, CMOS input, rail-to-rail output precision amplifier featuring a high gain bandwidth of 17 MHz and an enable pin for power management. It utilizes a CMOS input stage to achieve an ultra-low input bias current of 100 fA and an input referred voltage noise of 5.8 nV/√Hz.
| Input offset voltage | ±150 µV (max) |
|---|---|
| Input bias current | 100 fA |
| Unity gain bandwidth | 17 MHz |
| Supply current | 1.15 mA |
| Supply voltage range | 1.8V to 5.5V |
| Operating temperature range | -40°C to 125°C |
| Package type | 6-pin TSOT23 |
The device operates with a supply voltage range of 1.8V to 5.5V.
In shutdown mode, the amplifier draws only 140 nA of supply current.
The input offset voltage is guaranteed to be less than ±580 µV at maximum limits.
