NE5210 is a low-noise, wide-band transimpedance amplifier from Philips Semiconductors, suitable for signal recovery in fiber-optic receivers. It features single 5V supply, 280MHz bandwidth, differential outputs, low input/output impedances, high power supply rejection ratio, high overload threshold current, wide dynamic range, and 7kΩ differential transresistance.
The NE5210 is a wideband, low-noise transimpedance amplifier featuring differential outputs and a single 5V supply. It is specifically designed for signal recovery in fiber-optic receivers but is also applicable to various RF applications as a general-purpose gain block.
Key features include a bandwidth of up to 280MHz, a differential transresistance of 7kΩ, low input/output impedances, and high power supply rejection. The device operates over an ambient temperature range of 0°C to +70°C.
| Transresistance (differential) | 7 kΩ |
|---|---|
| Bandwidth (-3dB) | 280 MHz |
| Supply Voltage | 4.5 to 5.5 V |
| Operating Temperature Range | 0 to +70°C |
It is particularly suitable for signal recovery in fiber-optic receivers.
The device operates within an ambient temperature range of 0 to +70°C.
The typical supply current is 26 mA when tested at Vcc=5V and Ta=25°C.
The maximum input amplitude is 650 mVp-p when tested with Test Circuit 7.
