The NE/SA5204A is a wide-band high-frequency amplifier with a fixed gain of 20dB. It is ideal for cable TV applications.
The NE/SA5204A is a high-frequency amplifier designed by Philips Semiconductors, featuring a fixed insertion gain of 20dB and a bandwidth greater than 350MHz. It operates with a single supply voltage of 6V and draws a typical current of 25mA. The device is fabricated on a rugged 2um bipolar process and is well-matched to both 50Ω and 75Ω input and output impedances.
| Insertion Gain (Typical) | 20dB |
|---|---|
| Bandwidth (-3dB) | > 350MHz |
| Supply Voltage | 6V |
| Supply Current (Typical) | 25mA |
| Noise Figure (75Ω system) | 4.8dB |
| Operating Temperature Range (NE grade) | 0 to +70°C |
The minimum guaranteed bandwidth is relaxed to 350MHz.
No, no external components are needed other than AC-coupling capacitors.
