ZORBAX SB-AQ RRHT threaded columns are specially designed for higher pressure operation (up to 600 bar) and are packed with a high-performance microparticulate packing for high-speed reversed-phase HPLC. The StableBond AQ packing is made by chemically bonding a reversed-phase proprietary alkyl group to a specially prepared, high-purity ZORBAX porous silica microsphere. The special ZORBAX silica support is designed to reduce or eliminate strong adsorption of basic compounds. The densely covered, sterically protected stationary phase is chemically stable and gives longer column life. As a result, ZORBAX SB-AQ is a stable, reversed-phase packing that can be used for basic, neutral, or acidic samples. It is particularly well-suited for use with aggressive mobile phases (for example, pH < 2, high ionic strength, ion-pair additives, etc.) since the steric protection of the bonded phase resists degradation caused by such mobile phases. This material has also been shown to be stable when operated at temperatures up to 80 °C. These characteristics are particularly important for use in methods that need long-term stability and reproducibility. ZORBAX SB-AQ is especially suited in applications that use high-sensitivity detectors that require low backgrounds (for example, mass spectrometers). The uniform, spherical, ZORBAX SB-AQ particles have a controlled pore size of 80Å. Columns are loaded to a uniform Agilent ZORBAX SB-AQ RRHT Threaded Column Data Sheet be
The Agilent ZORBAX SB-AQ RRHT threaded columns are engineered for high-pressure liquid chromatography (HPLC) applications, supporting operation up to 600 bar. These columns utilize StableBond AQ packing, which features a chemically bonded reversed-phase alkyl group on high-purity ZORBAX porous silica. This design reduces the adsorption of basic compounds and provides steric protection against degradation from aggressive mobile phases, such as those with low pH or high ionic strength. The columns are particularly suitable for use with high-sensitivity detectors like mass spectrometers due to their low background noise.
| Maximum Operating Pressure | 600 bar (9,000 psi) |
|---|---|
| Maximum Operating Temperature | 80 °C |
| pH Range | pH 1.8 to 8.0 |
| Particle Pore Size | 80A |
| Column ID Support (4.6 mm) | 1,000 bar |
The maximum operating pressure is 600 bar (9,000 psi).
The columns should be used within a pH range of 1.8 to 8.0.
Yes, the StableBond AQ packing is designed to reduce or eliminate strong adsorption of basic compounds.
