The Varian 500-MS LC ion trap is an ion trap based LC/MS system. The 500-MS exceptional sensitivity, mass stability, resolution and enhanced charge capacity (ECC™) makes the 500-MS LC ion trap the system of choice for pharmaceutical, clinical toxicological, environmental, and other applications.
The Varian 500-MS LC ion trap is an ion trap based LC/MS system designed for high sensitivity, mass stability, resolution, and enhanced charge capacity. It serves as a preferred choice for pharmaceutical, clinical toxicological, environmental, and other analytical applications.
The instrument features an Atmospheric Pressure Ionization (API) interface with selectable Electrospray Ionization (ESI) or Atmospheric Pressure Chemical Ionization (APCI) sources. The ESI source supports flow rates from 1 to 1000 pL/min, while the APCI option accommodates flows up to 2 mL/min. Both interfaces utilize a SelecTemp feature for temperature programming of drying gas.
| Mass range | 50 to 2000u |
|---|---|
| Resolution | <0.5u FWHM over the entire range |
| Mass axis stability | + 0.1u over 24 hours at constant temperature |
| Max ion time | 500,000 psec |
| Drying gas temperature (ESI) | 400°C max |
| LC flow range (ESI) | 1 to 1000 pL/min |
| Needle voltage (ESI) | 6 kV max |
| LC flow range (APCI) | 100 pL/min to 2 mL/min |
| Auxiliary gas temperature (APCI) | 550°C max |
| Power requirements | 100-120, 200-240 Vac, +10 %, 50/60 Hz, 3200 VA (steady state) |
| Operating Temperature | 16°C to 30°C |
| Weight (MS) | 135 lb/ 62 kg |
The mass range is from 50 to 2000u.
Yes, SelecTemp allows temperature programming of the drying gas throughout the analysis.
The system requires 100-120, 200-240 Vac at +10%, 50/60 Hz with a steady state of 3200 VA.
