EZChrom Elite conveniently displays data results in a single screen for easy viewing. With the optional JASCO PDA control, 3D spectral information is also collected with each run. Control the JASCO HPLC with EZChrom Elite JASCO HPLC systems are in widespread use in HPLC laboratories throughout the world. Agilent Technologies now provides JASCO HPLC Control Software as an optional software add-on for EZChrom Elite. This software provides instrument control for a wide range of JASCO autosamplers, pumps, and detectors. JASCO PDA detectors also require the JASCO PDA Control Software. The JASCO 1500 and 2000 Series HPLC systems and the X- LC HPLC system are supported. Flexible Control of JASCO Pumps and Detectors The software provides full pump control; all gradient information, flow, auxiliary pump, events and valve controls and a Time Program to specify flow and concentrations as a function of time are provided. Multiple pumps can be configured for a single instrument. JASCO UV and Fluorescence detectors can be setup in software to specify wavelength, autozero controls, detector outputs as well as a time program to specify desired wave- lengths and other parameters as a function of time. JASCO HPLC Control Software for EZChrom Elite™ Chromatography Data System Key Benefits • Fully integrated instrument control and data handling of Jasco 2000,1500 series HPLC and X-LC system through EZChrom Elite. • Support multi-vendor instrumentation in a single CDS solution. • Select
This document describes Agilent Technologies' JASCO HPLC Control Software as an optional software add-on for EZChrom Elite. It provides instrument control for a wide range of JASCO autosamplers, pumps, and detectors, including the JASCO PDA Control Software required for PDA detectors.
The document details the supported JASCO 1500 Series, 2000 Series, and X-LC HPLC systems. It lists specific minimum firmware requirements (Rom Version) for various modules such as pumps, autosamplers, column ovens, UV/Vis detectors, fluorescence detectors, PDA detectors, and chiral detectors to ensure compatibility with the software.
| Required Software Version | EZChrom Elite version 3.1.7 |
|---|---|
| Supported Systems | JASCO 1500 Series, 2000 Series, X-LC HPLC system |
| Pump Control Features | Full pump control; all gradient information, flow, auxiliary pump, events and valve controls |
| Detector Support (1500 Series) | UV-1570 UV/VIS Detector 1.18 |
EZChrom Elite version 3.1.7 is required.
Yes, but it requires the optional JASCO PDA Control Software.
Yes, a special EZChrom SI (Single Instrument) version is available.
