The Series 39 Signal Conditioning Modules is a microprocessor-based signal conditioning module offers rugged construction and linearized 0-5 volt outputs. The Series 39s are designed to be used in conjunction with Series 44 Temperature probes.
This document provides specifications for the Series 39 Signal Conditioning Modules, which are microprocessor-based units used with Series 44 Temperature Probes. These modules offer rugged construction with stainless steel housings and gasket sealing to withstand adverse environments, operating within a temperature range of -25°C to +80°C.
| Signal Conditioning Output Voltage | 0.000 to 5.000 +/- 0.025 VDC |
|---|---|
| Probe Insertion Length (Series 44) | 2" to 30" |
| Media Connection Pressure Rating | 2000 PSI |
| Response Time (Liquid Level Probe) | Less than 0.25 sec |
The Series 39C -6-5 covers a range of -255°C to -245°C.
The excitation current is 1.0 mA DC, and they are four leaded.
They are designed for use with liquid oxygen, liquid hydrogen and liquid nitrogen.
