M-Audio Revolution 7.1 User Guide

Q: What are the minimum system requirements for stereo operation on Windows?

The minimum requirements are an Intel Celeron 350MHz or AMD K6ll 500MHz processor, 128MB RAM, a CD-ROM drive, and Windows Me, 2000, or XP.

Q: Does the Revolution 7.1 support digital output formats?

Yes, it supports 24-bit Linear PCM, 16-bit Linear PCM, 16-bit AC-3, Dolby Pro Logic, or DTS over the coaxial connector.

Q: What software technologies are included with the driver installation?

The driver software includes SRS Circle Surround II and TruSurround XT technologies.

This document introduces the features and characteristics of Revolution 7.1, system requirements, package contents, hardware installation and software installation.

M-Audio Revolution 7.1 User Guide - cover page

Brand: M-Audio
Category: Other Computer Accessories
Document type: User Manual
Language: English
Pages: 30
File format: PDF
File size: 859 KB
Published: 04 July, 2012
Updated: 30 September, 2023
Model: Revolution 7.1
MD5 checksum: C1F0549FB37DF9774EB6BCEECF5F29E9
PDF: M-Audio Revolution 7.1 User Guide PDF

About this manual

The M-Audio Revolution 7.1 is a PCI audio interface designed to bring 24-bit, 192kHz audio performance and virtual surround sound to PC and Macintosh computer systems. This guide details the hardware installation of the PCI card and the software installation of the drivers and SRS technologies.

What's inside

Introduction
System Requirements
Package Contents
Hardware Installation
Software Installation
Physical Connections
Revolution 7.1 Control Panel
Troubleshooting
Warranty Information
Technical Specifications

Specifications

Audio Playback Resolution	24-bit/192kHz
Audio Recording Resolution	24-bit/96kHz
Signal-to-Noise Ratio	107 dB
Total Harmonic Distortion + Noise	<0.00235%
Warranty Period	One-year

Frequently asked questions

What are the minimum system requirements for stereo operation on Windows?
