This is a product manual for M-Audio Sputnik multi-pattern vacuum tube large-diaphragm condenser microphone.
The M-Audio Sputnik is a multi-pattern, dual-sided large-diaphragm studio condenser microphone featuring a custom double-sided capsule with gold-evaporated Mylar diaphragms. It is designed to deliver a lush, classic sound suitable for professional recording applications.
| Diaphragm material | gold evaporated Mylar |
|---|---|
| Diaphragm thickness | 3 microns |
| Construction material | solid brass |
| Polar patterns | Cardioid, Omnidirectional, Figure-8 |
The box contains the Sputnik microphone, power supply, 7-pin cable, grounded IEC power cable, flight case, shock mount, soft cloth bag, and the owner's manual.
It takes about 15 seconds for the red power LED to illuminate fully, but it is recommended to wait a few minutes for the operating voltages to stabilize.
No, you should not use the +48V phantom power function on your preamp because the Sputnik power supply unit provides the voltages needed to power the mic.
