Studiophile BX5a Deluxe dual-amped studio near-field monitor speakers user guide, introducing the characteristics and usage methods of the speaker.
The M-Audio Studiophile BX5a Deluxe is a self-powered, bi-amplified studio near-field monitor speaker designed to deliver pure, original sound without coloration. It features a 5-inch Kevlar woofer and a 1-inch silk dome tweeter, both magnetically shielded for desktop use. The system includes two separate power amplifiers (40W for the woofer and 30W for the tweeter) to ensure balanced frequency response.
| LF Driver | 5-inch Kevlar curved cone with high temperature voice coil and damped rubber surround |
|---|---|
| HF Driver | 1-inch magnetically shielded natural silk dome |
| Frequency Response | 56Hz - 22kHz |
| Crossover Frequency | 3kHz |
| LF Amplifier Power | 40W |
| HF Amplifier Power | 30W |
| S/N Ratio | > 100dB typical A-weighted |
| Input Connectors | 1 x XLR balanced input connector, 1 x TRS balanced/unbalanced input connector |
| Power Requirements | factory programmed for either 115V ~50/60Hz, 230V~50/60Hz or 100V~50/60Hz |
| Dimension | 250 mm (H) x 176 mm (W) x 200 mm (D) |
The box contains two BX5a Deluxe speakers, two detachable AC power cords, and this manual.
The two units and the listener should align to form a regular triangle, with the top of the woofers level with your ears.
The speakers accept 1 x XLR balanced input connector and 1 x TRS balanced/unbalanced input connector.
